Product Designation |
Description |
Typical Application/Benefit |
Application Method |
Electrical Resistance |
|
| Silver Circuit Traces | |||||
|
CI-1001 |
Silver-vinyl ink, highly conductive, flexible |
Circuit traces / Low Ω, low cost |
Screen Print |
< 0.015 |
|
|
CI-1028 |
Silver-polyester ink, high solids, wear resistant, fast dry |
Circuit traces / fine line printable, long switch actuation life |
Screen Print |
< 0.020 |
|
|
CI-1036 |
Silver-urethane ink, highly conductive, highly flexible |
Circuit traces / lowest Ω, highly creasable |
Screen Print |
< 0.010 |
|
| Carbon Resistors, Contact Pads | |||||
|
CI-2001 |
Carbon-vinyl ink, general purpose |
Top coat for silver contacts, can blend with CI-1001 to target resistance |
Screen Print |
< 20 |
|
|
CI-2002 Series |
Carbon inks, stable resistance |
Varied resistance blends for target resistance matching |
Screen Print |
20 – 100,000 |
|
|
CI-2014 |
Carbon ink, low ohm |
Low cost, no migration traces or electrodes |
Screen Print |
< 10 |
|
|
CI-5001 |
Nickel ink, highly wear resistant for ZIF connectors, low ohm |
ZIF tail contacts and jumpers, print in one pass |
Screen Print |
< 5 |
|
| Dielectric Insulators | |||||
|
DI-7502 |
Dielectric, UV cure |
Silver trace and cross-over junction insulation, highly flexible |
Screen Print |
>1,000 Mega ohms |
|
|
DI-7510 |
Dielectric, UV Cure for print-treated polyester film |
Silver trace and cross-over junction insulation, moisture resistant |
Screen Print |
>1,000 Mega ohms |
|
|
DI-7009 |
Heat cure insulator |
Silver trace insulation, highly flexible |
Screen Print |
>100 Mega ohms |
|
| Miscellaneous | |||||
|
DB-1501 |
Silver epoxy, single component |
SMD attachments, high shear strength, long stencil life |
Stencil Print |
0.0004 ohm-cm |
|
|
DB-1526 |
Silver epoxy, two component |
SMD attachment, low temp cure |
Needle Dispense |
0.003 ohm-cm |
|
|
DI-7801 |
UV pressure sensitive adhesive |
Selectively print PSA, eliminate die-cut tapes |
Screen Print |
>1,000 Mega ohms |
|
|
DI-7511 |
UV spacer |
Thick printing for spacer formation, good insulation for silver traces |
Screen Print |
>1,000 Mega ohms |
|
|
CI-1035 |
Silver-polyester, adhesion and stress compatible with ITO coated film. |
Capacitive or transparent touch switch, low temp cure |
Screen Print |
< 0.025 |
|
